Media Converter
Highlights
- Conversion between Ethernet (copper) and fiber optic (FOC)
- Support for single-mode and multi-mode fiber
- Gigabit Ethernet support (1000Base-T ↔ 1000Base-SX/LX)
- DIN-rail mounting (EN 50022)
- Web configuration via HTTPS
- Industrial temperature range -10°C to +70°C
Ethernet to fiber optic (FOC) – Gigabit media converters for single-mode and multi-mode fiber. DIN-rail mounting, -10 to +70°C, web configuration. Ideal for network extension over large distances.
Ethernet-to-fiber converters for industrial networks. The media converters enable transparent conversion between copper Ethernet and fiber optic cable (FOC) – for distances up to 120 km in single-mode operation.
Technical Highlights
- Gigabit Ethernet: 1000Base-T (copper) ↔ 1000Base-SX/LX (fiber)
- Single-mode and multi-mode: Distances up to 550 m (MM) or up to 120 km (SM)
- Transparent transmission: No IP routing, Layer-2 transparency
- DIN-rail mounting: EN 50022, 9-24V DC supply
- Web configuration: HTTPS interface for status and configuration
- Industrial temperature: -10°C to +70°C operating temperature
Application Areas
- Bridging large distances in factory and campus networks
- Connecting remote buildings or plant sections via fiber
- Protection against electromagnetic interference (galvanic isolation)
- Migration of existing Ethernet infrastructure to fiber
- Integration into industrial automation networks
Specifications
| Property | Value |
|---|---|
| Ethernet Standard | 10/100/1000Base-T (copper), 1000Base-SX/LX (fiber) |
| Fiber Type | Multi-mode (SX, up to 550 m) or single-mode (LX, up to 120 km) |
| Connectors | RJ45 (copper), SC/LC duplex (fiber) |
| Configuration | Web interface (HTTPS), SNMP optional |
| Power Supply | 9–24V DC |
| Mounting | DIN rail (EN 50022) |
| Operating Temperature | -10°C to +70°C |
| Protection | IP30 |
FAQ
Multi-mode (MM) is suitable for short distances (up to 550 m) and less expensive to procure. Single-mode (SM) bridges distances up to 120 km and is used for long runs between buildings or sites. Please specify the distance you need to bridge when inquiring.
Yes, the media converter operates transparently at Layer 2 – it appears to all connected devices like a simple cable. No configuration changes to your switches or routers are required.
With multi-mode fiber (50/125 µm) up to 550 m is possible. With single-mode fiber you can reach distances up to 120 km – depending on the wavelength and SFP module used. We advise you on the selection.
Fiber cables and accessories (patch cables, cable installation sets) can be supplied on request. For installation we work with qualified network installers. Contact us for details.
